The application of microwave technology provides a new heating method for industrial heating, which has been widely used in industry, agriculture, chemical industry, medical and other aspects.
Firstly, using its thermal effect, it is mainly used for heating and drying of food, medicinal materials, agricultural and sideline products, wood, cardboard, chemical industry products, etc. Second,using its biological effects to sterilize food, medicinal materials, agricultural and sideline products, etc. at low temperature, anti-mildew insurance, Cui Chen and alcoholization of liquor, and suspend fermentation and breeding. As a high-tech today, microwave heating has long moved from the laboratory to the practical stage of production, and the prospects are very broad.
Application of tunnel microwave paper curing machine:
Microwave cardboard drying equipment is mainly used in paper industry, cardboard, paper tube, paper tube, grey cardboard, paper character film, adhesive paper board and other paper industry drying; All kinds of cardboard, grey cardboard, kraft paper, carton, pulp, honeycomb cardboard, pulp model drying and curing shaping.
Features of paper drying machine:
Microwave cardboard,paper tube drying equipment,microwave drying machine,continuous industrial drying machinery for paper products,microwave paper cardboard dehydrator is a modern high-tech production equipment,it has changed the traditional heating and drying cardboard heat transfer method.Microwave don’t need preheat and heat transfer,directly heat from inside to outside at the same time.And the heating uniformity,don’t has coking phenomenon. But the traditional hot air transfer because some time low-temperature,some high temperature,resulting in different angles of coking and inside coking outside endogeny phenomenon,uneven heating.
Microwave paper products drying equipment can work continuously,easy to control,advanced craftwork,only one person can operate this machine,save labor.
Microwave have strong penetration for cardboard,practice shows that in cardboard production process, microwave drying compared with conventional process,not only fast drying speed,low power consumption,but also greatly improved the product quality.
Specific performance of continuous paper curing equipment:
1. Strong glue,greatly improved water resistance and compressive strength.
2. Fast drying,cardboard uniform,flat,small change.
3. Have strong sterilizing function while in microwave drying process,greatly improved mildew resistance ability.
4. Compared with far infrared drying,drying time short two-thirds,electricity consumption save 1/3.
Following are YM-40 specification for reference :
Power supply | 380V±10% 50HZ±1% three-phase five-wire |
Microwave Output Frequency | 2450±50MHz |
Microwave input apparent power | 54KVA |
Microwave output power | 40KW |
Microwave power adjustment range | 0-40KW(adjustable) |
Ambient temperature | -5-40°C |
Relative humidity | ≤80%, Surrounding environment:no corrosive gas, conductive dust and explosive gas |
Overall dimension(L*W*H) | 10500*1440*1750 mm |
Transmission speed | 0-10m/min(adjustable) |
Height of the inlet and outlet | 60 mm (Customized) |
Microwave leak | accord with a country GB10436-89 standards(<5 mw/cm^2) |
Equipment safety | accord with GB-5226Electrical safety standard accord with a country GB16798-1997 Food machinery health security index |
Microwave machine size & Power supply & Conveyor Belt speed & Microwave power & The height of inlet out &The height of conveyor belt from the ground ，all can be CUSTOMIZED .
